316L Stainless Steel Plate DIN1.4404 Stainless Steel Plate ASTM a240 Grade 316L Stainless Steel Metal Plate
Type 316L is a variant of Type 316 and differs by having a lower Carbon content as well as slightly lower yield and tensile strengths. Type 316L offers improved weldability and also reduces the possibility of lower corrosion resistance around welded areas.
1. Products Details
| Commodity | 300 Series 316 Stainless Steel Plate |
| Grade | 301,302,304,304L,316,316L,310S,309S,321,301,310 |
| Brand | TISCO ,BAOSTEEL,POSCO,JISCO,LISCO |
| Certification | SGS,BV,IQI,TUV,ISO,etc |
| Thickness | 0.3mm-3.0mm |
| Width | 1000,1219,1250,1500mm, or as your requirements |
| Length | 2000,2438,2500,3000,6000mm, or as your requirements |
| Surface | No.1, 2B, BA, 8K Mirror, Hairline,satin, Embossed,brush,No.4,HL,matt,pvc film,laser film. |
| Standard | ASTM,AISI,SUS,JIS,EN,DIN,GB, ASME,etc |
| Delivery | 5-7 days after confirming the order |
| MOQ | 1 Ton |
2. Chemical Properties:
| | C | Mn | Si | P | S | Cr | Mo | Ni | N |
316
(S31600) | 0.08
max | 2.0
max | 0.75
max | 0.045
max | 0.03
max | min: 16.0
max: 18.0 | min: 2.0
max: 3.0 | min: 10.0
max: 14.0 | 0.10
max |
316L
(S31603) | 0.03
max | 2.0
max | 0.75
max | 0.045
max | 0.03
max | min: 16.0
max: 18.0 | min: 2.0
max: 3.0 | min: 10.0
max: 14.0 | 0.10
max |
Mechanical Properties:
| Grade | Tensile Strength
ksi (min) | Yield Strength
0.2% ksi (min) | Elongation % | Hardness (Brinell) MAX | Hardness
(Rockwell B) MAX |
316
(S31600) | 75 | 30 | 40 | 217 | 95 |
316L
(S31603) | 70 | 25 | 40 | 217 | 95 |
3. 316L 316 316Ti PROCESSING OF Laser Cutting
And compared to traditional oxygen acetylene, such as plasma cutting technology, laser cutting speed, narrow kerf width, small heat affected zone, vertical degree good, trimming smooth kerf edge, at the same time can be variety of laser cutting materials, including carbon steel, stainless steel, alloy steel, wood, plastic, rubber, cloth, quartz, ceramic, glass, composite materials, etc.With the rapid development of market economy and the progress of science and technology, laser cutting technology has been widely used in automobile, machinery, electricity, hardware and electrical appliances and other fields.
