3.0 - 120mm thickness grade 317L ferrite stainless steel plate SGS, BV certificate
Quick Detail
grade 317L stainless steel plate
size: 1500 x 3000mm 1500 x 6000mm thickness: 3.0mm - 120mm
Brand: TISCO BAOSTEEL AUTO KUMPO
high quality and fast deliver
317L stainless steel plate
| PRODUCTS | 317L stainless steel plate | Brand | TISCO BAOSTEEL |
|
size | 1500x3000mm
1500x6000mm
Or as required |
surface
| original: NO.1
traetment: NO.4 mirror |
| thickness | 3.0-120mm | Certificate | SGS, BV |
Description
| Material | Ferrite stainless steel, magnetic. |
| Standard | AISI, ASTM, EN, GB, DIN, JIS |
| Technology | Cold Rolled Or Hot Rolled |
| Thickness | 0.2-120mm (tolerances ±0.02mm) |
| Width | 500-2000mm (tolerances ±6.00mm) |
| The sizes or thicknesses of stainless steel coil can be customized, if you need additional information, please don’t hesitate to contact us at any time. |
Feather and Applications
317 l (00 cr19ni13mo3, UNS S31726) alloy is based on molybdenum austenitic stainless steel. It with conventional chrome - nickel austenitic stainless steel, such as, compared to 304 alloy has the stronger ability of resistance to chemical corrosion. In addition, compared with the conventional stainless steel, 317 l alloy has higher ductility, resistance to stress corrosion performance, compressive strength and resistance to high temperature performance. It is a low carbon level or L level, this level has during the welding and heat treatment process the sensitization effect of resistance.
Specifications
Relative 316 l, 317 l steel has excellent water resistance and resistance to SCC, used for Chemical ships, Chemical products, such as Reactor should be high corrosion-resistant Chemical equipment.
SUS317L mechanical properties
| YS (Mpa) | TS (Mpa) | EL (%) | HV |
| >=176 | >=480 | >=40 | <=200 |
SUS317L chemical composition
| C | Mn | Si | P | S | Cr | Ni | Mo |
| <=0.030 | <=2.00 | <=1.00 | <=0.045 | <=0.030 | <= 18.0 ~ 20.0 | <= 11.0 ~ 15.0 | <=3.0 ~ 4.0 |
Density(g/cm3) : 7.93
Advantage of us:
1, high quality and competitive price
2, have 15000 ton stainless steel products stock
3, fast deliver
4, more than 12 years export experience
5,Near Shanghai Port, the traffice is very good.
6, warm service
