S31254 PLATE 254 SMO Hot Rolled Plate SA 240 UNS S31254 Plate SS 254 SMO F44 Plates

  • 1
  • 2
  • 3

Brand Name : Mittel

Model Number : 254SMO F44 S31254

Certification : SGS ISO MTC

Place of Origin : China

MOQ : 100KGS

Price : 15 USD/KG

Payment Terms : L/C, T/T

Supply Ability : 80000KGS

Delivery Time : 7 Working Days

Packaging Details : Wooden Pallet BOX

Material : stainless steel

Thickness : 1-30mm

Surface : Mirror or matt

Width : 1000-2000mm

Length : 2000-6000mm

Shape : flat Plate

Contact Now

Alloy 254 UNS S31254 PLATE 254 SMO Plate, SA 240 UNS S31254 Plate SS 254 SMO F44 Plates



SMO 254 / UNS S31254 Sheets & Plates Specifications

Specifications for SMO 254 / UNS S31254 Sheets & Plates. If any specification is not mentioned here, please use the contact button for quick quote.

Specifications ASTM A240 / ASME SA240
Thickness 4mm-100mm
Width 1000mm, 1219mm, 1500mm, 1800mm, 2000mm, 2500mm, 3000mm, 3500mm, etc
Length 2000mm, 2440mm, 3000mm, 5800mm, 6000mm, etc
Surface 2B, 2D, BA, NO.1, NO.4, NO.8, 8K, mirror, checkered, embossed, hair line, sand blast, Brush, etching, etc
Finish Hot rolled plate (HR), Cold rolled sheet (CR), 2B, 2D, BA NO(8), SATIN (Met with Plastic Coated)
Form Coils, Foils, Rolls, Plain Sheet, Shim Sheet, Perforated Sheet, Chequered Plate, Strip, Flats, Blank (Circle), Ring (Flange) etc.

SMO 254 / UNS S31254 Sheets & Plates Chemical Composition

Grade SMO 254
Ni 17.5 – 18.5
Cr 19.5 – 20.5
Mo 6 – 6.5
Cu 0.5 – 1.0
N 0.18 – 0.22
C 0.02
Mn 1.0
Si 0.08
P 0.03
S 0.01

SMO 254 / UNS S31254 Sheets & Plates Mechanical Properties

Grade SMO 254
Density 8.0 g/cm3
Melting Point 1320-1390 °C
Yield Strength (0.2%Offset) 300
Tensile Strength 650
Elongation 35 %

SMO 254 / UNS S31254 Sheets & Plates Equivalent Grades

STANDARD SMO 254
UNS S31254
WERKSTOFF NR. 1.4547
AFNOR Z1 CNDU 20.18.06Az
EN X1CrNiMoCuN20-18-7
SIS 2378

Applications of S31254 Stainless Steels: Applications are as under:

  • Elevated oil distillation columns
  • Exhaust gas desulfurization scrubbers
  • Pumps
  • Chokes
  • Industrial components for oil and gas
  • Industrial components for food processing equipment
  • Valves
  • Pipework
  • Saltwater handling
  • Flanges & manifolds
  • Industrial components for chemical industry
  • Bleaching equipment in the pulp & paper industry
  • Desalination
  • Heat exchangers



S31254 PLATE 254 SMO Hot Rolled Plate SA 240 UNS S31254 Plate SS 254 SMO F44 PlatesS31254 PLATE 254 SMO Hot Rolled Plate SA 240 UNS S31254 Plate SS 254 SMO F44 Plates
