Soild Alloy Bar (FORGED) MATERIAL ASTM A29/A29M GR. 4140 High Tensile Hot Rolled Steel Round Bar

Name: Soild Alloy Bar FORGED MATERIAL ASTM A29A29M GR 4140 High Tensile Hot Rolled Steel Round Bar
Brand: TSINGSHAN
Price: 1.45 USD

Buy cheap Soild Alloy Bar (FORGED) MATERIAL ASTM A29/A29M GR. 4140 High Tensile Hot Rolled Steel Round Bar product

Brand Name : TSINGSHAN

Model Number : 4140

Certification : ISO MTC

Place of Origin : China

MOQ : 100KGS

Price : USD1.45/KG

Payment Terms : L/C, T/T

Supply Ability : 50000KGS

Delivery Time : 7 Days

Packaging Details : Wooden Box

Surface Treatment : Black/Peeling/Polishing/Machined

Length : Customizable

Color : Metallic

Physical Properties : Specific Gravity 7.85

Transport Package : Nude Packing or as Requested

Ends : Beveled/plain

Surface : Black and Bright

Type : Carbon Steel Bar

Service : Cutting

Secondary Or Not : Non-secondary

Tolerance : Standard

Size Ranfe : Φ20-500

Tech : Hot rolled

Delivery Condition : annealed,hot rolled/forged

Contact Now

Soild Round Bar (FORGED) MATERIAL ASTM A29/A29M GR. 4140 Hardness 300~400BHN

Product Description

SCM440 42CrMo4 SAE AISI 4140 EN19 1.7225 High Tensile Hot Rolled Steel Round Bar Steel Bar

EN19 AISI 4140 42CrMo4 is a alloy structural steel, which is used for engineering structural, like high tensile shafts, bolts and nuts, gears, pinions and spindles. Locomotive traction with the big gear, supercharger drive gear, pressure vessel, rear axle, gear load of connecting rod and a spring clip.

1.Supply Size range
Hot Rolled en19 steel bar: Ø16mm-310mm
Forging en19 steel bar: Ø260mm-1000mm
Q&T (Quenched&tempered):Ø16-1000mm
Cold drawn bright steel bars : 5mm to 120mm

2.Equivalent Grades

GB,YB	JIS	DIN(W-Nr.)		BS	NF
42CrMo	SCM440/(SCM4)	42CrMo4-1.7225	4140	708M40/709M40/708A42/EN19	42CD4

3.Chemical composition

ASTM A29/29M	C	Si	Mn	Cr	Mo	P	S
4140	0.38~0.43	0.15~0.35	0.75~1.00	0.80~1.10	0.15~0.25	≤0.035	≤0.040
DIN WN-r	C	Si	Mn	Cr	Mo	P	S
1.7225	0.38~0.45	≤0.40	0.60~0.90	0.90~1.20	0.15~0.30	≤0.035	≤0.035
GB/T	C	Si	Mn	Cr	Mo	P	S
42CrMo	0.38~0.45	0.17~0.37	0.50~0.80	0.90~1.20	0.15~0.25	≤0.030	≤0.030
BS	C	Si	Mn	Cr	Mo	P	S
708M40	0.36~0.44	0.10~0.35	0.70~1.00	0.90~1.20	0.15~0.25	≤0.035	≤0.035
JIS	C	Si	Mn	Cr	Mo	P	S
SCM440	0.38~0.43	0.15~0.35	0.60~0.85	0.90~1.20	0.15~0.30	≤0.030	≤0.030

4.Heat Treatment for 4140 steel round bars
4140 alloy steel material is a high quality Quenched and Tempered Alloy Structural steel, It belong to the high quality medium carbon alloy steel, Oil Quenched & Tempered Hardenss is 28-34 HRC.4140 Annealing delivery hardenss less than 250HB

Heat treatment of aisi 4140 steel
Annealing
AISI 4140 alloy steel is annealed at 872°C (1600°F) followed by slowly cooling in the furnace.
Tempering
AISI 4140 alloy steel can be tempered at 205 to 649°C (400 to 1200°F) depending upon the desired hardness level. The hardness of the steel can be increased if it has lower tempering temperature
Hardening
AISI 4140 alloy steel can be hardened by cold working, or heating and quenching. Soild Alloy Bar (FORGED) MATERIAL ASTM A29/A29M GR. 4140 High Tensile Hot Rolled Steel Round Bar
