Soild Bar SUS 316 Ø1/2" ASTM A276 TP316L Stainless Steel Round Bar OD 6-300mm
| Material | 304,304L,309S,310S,316,316L,316Ti,317,317L,321,347H,201,202,405,409,
410,420,430,etc |
| Type | Round,square,hexagonal,flat,angle |
| Surface | Pickled,Black,Bright,Polishing,Blasting,etc |
| Specifications | Round bar Diameter: 0.1mm~500mm |
| MOQ | 1Ton |
| Length | 6m,5.8m,3m or as required |
| Price Term | EX-Work, FOB, CFR, CIF,CNF |
| Payment Term | T/T,L/C, Western union |
| Market | Europe,South America, Africa ,Oceania ,such as :Chile,Spain,USA,Germany,India,Dubai,Iraq,Vietnam,Ireland,Korea,Singapore,and so on. |
| Package | Bundled,wooden box for export standard package. |
| Delivery Time | Normally according to the order quantity |
| Contact | If you have any question, please feel free to contact me |
AISI 316L Stainless Steel (UNS S31603)
AISI 316L stainless steel is a modified ultra-low carbon Cr-Ni-Mo series austenitic stainless steel based on AISI 316. It is recommended for parts that cannot be annealed after welding in certain corrosive environments. The addition of molybdenum can provide pitting resistance in phosphoric acid and acetic acid and dilute chloride solutions and corrosion resistance in sulfurous acid. SS316L is resistant to carbide precipitation in the temperature range of 425-870 °C (800-1600 °F), so normal welding can be performed without reducing corrosion resistance. However, when it is heated and kept in the sensitization temperature range for a long time during use, a large amount of carbides will precipitate, so it is usually recommended to use it below 425 °C (800 °F).
Type 316L Stainless Steel Properties
Type 316L stainless steel density is 0.289 lb/in3 (8.0 g/cm3); melting point is 1375-1400 °C (2500-2550 °F); 0.2% yield strength is minimum 25 ksi (170 MPa) in annealed and hot finished condition, minimum 45 ksi (310 MPa) in annealed and cold finished condition; Minimum tensile strength is 70 ksi (485 MPa) in annealed and hot finished condition, ≥ 90 ksi (620 MPa) in annealed and cold finished condition; Maximum Brinell hardness is 217 HB, Maximum Rockwell hardness is 90 HRBW; Thermal conductivity is 12.1 W/m·K at 20 °C (68 °F), 16.3 W/m·K at 100 °C (212 °F).
Chemical Composition
| 316L Stainless Steel Composition, % |
| ASTM Standard | AISI | C, ≤ | Si, ≤ | Mn, ≤ | P, ≤ | S, ≤ | Cr | Ni | Mo | N, ≤ |
| ASTM A276/A276M | 316L | 0.03 | 1.00 | 2.00 | 0.045 | 0.030 | 16.0-18.0 | 10.0-14.0 | 2.00-3.00 | – |
| ASTM A240/A240M | 316L | 0.03 | 0.75 | 2.00 | 0.045 | 0.030 | 16.0-18.0 | 10.0-14.0 | 2.00-3.00 | 0.10 |
Physical Properties
Grade 316L stainless steel physical properties are listed in the table below such as density, melting point, specific heat, electrical resistivity, elastic modulus (modulus of elasticity), thermal conductivity, etc.
FAQ
Q:What kind of work does your company do?
A:Our company is a professional manufacturer.
We mainly produce stainless steel plate/pipe/coil/round bars, as well as pipe fittings.
Q:What are the advantages of your company?
A:
(1): Prime quality and reasonable price.
(2): Wide excellent experiences with after-sale service.
(3): Every process will be checked by responsible QC which insures every product's quality.
(4): Professional packing teams which keep every packing safely.
(5): Trial order can be done in one week.
(6): Samples can be provided as your requirements.
Q:What is your terms of payment ?
A: 30% T/T in advance ,balance based on BL copy or LC at sight. Term can be FOB, CIF, CFR, EXW, etc.
Q:What about your price?
A:Our price is very competitive because we are a factory.
Pls feel free to contact us if you are interested in our products, more quantity will be better prices.
Q:How long is your delivery time?
A:Different products have different delivery time.The products will be delivered as soon as possible on the basis of the quality assurance.Usually the delivery time is within 5 days after we received your deposit.
Q:How long is your delivery time?
A:Different products have different delivery time.The products will be delivered as soon as possible on the basis of the quality assurance.Usually the delivery time is within 5 days after we received your deposit.
Q:How do you make our business long-term and good relationship?
A:We keep good quality and competitive price to ensure our customers benefit. We respect customer and we sincerely do business with them, sustain our service level before and after every deal.
Product Tags:
|
|
Soild Bar SUS 316 Ø1/2" ASTM A276 TP316L Stainless Steel Round Bar OD 6-300mm Images
|
