Alloy Grade 317L S31703 Stainless Steel Sheets 1250mm x 2438mm 2B Finished

Name: Alloy Grade 317L S31703 Stainless Steel Sheets 1250mm x 2438mm 2B Finished
Brand: TISCO
Price: 4.65 USD

Buy cheap Alloy Grade 317L S31703 Stainless Steel Sheets 1250mm x 2438mm 2B Finished product

Brand Name : TISCO

Model Number : 201 202 304 304L 309S 310S 316 316L 317L 321 400Series .etc

Certification : SGS,BV

Place of Origin : China(mainland)

MOQ : 1000KGS

Payment Terms : L/C, T/T, Western Union

Supply Ability : 1500Tons

Delivery Time : 5-10 days

Packaging Details : standard export seaworthy packing or as required

Price : 4.65USD/KG

grade : 201 304 304L 316L 321 310S 316L 317L 904L.etc

surface : 2B BA NO.4 mirror 8K Gold Mirror

standard : ASTM AISI GB DIN JIS EN

Thickness : 0.6mm - 3.0mm

Width : 1000mm 1219mm 1500mm 1800mm

Length : as required

Contact Now

Alloy Grade 317L Mile Stainless Sheets 1250mm x 2438mm 2B Finished

Quick Detail:
Size: 1000x2000mm 1219x2438mm 1500 x 3048mm
Thickness: 0.5 - 3.0mm
Tolerance: +-0-5%
Brand: TISCO BAOSTEEL.etc

Name	317L stainless steel sheet	Brand Name	TISCO BAOSTEEL
size	1219x2438mm 1000x2000mm Or as required	surface	2B BA NO.1 NO.4 HL 8K PVC
thickness	0.5-3.0mm	Certificate	SGS, BV

Description:

Alloy Grade 317L Mile Edge Stainless Sheets 1250 x 2438mm 2B Finished
stainless steel sheet / stainless steel plate / stainless steel coils / stainless steel strip / stainless steel
317L stainless steel sheet / 317L stainless steel / stainless steel sheet / Inox 1.4438

Description	ASTM A240 317L stainless steel sheet , 317L steel sheet, 317L stainless steel plate,317L steel plate ,317L SS sheet
standard	ASTM A240, JIS G4304, G4305, GB/T 4237, GB/T 8165, BS 1449, DIN17460, DIN 17441
Thickness	0.3mm-80mm
Width	500mm,1000mm,220mm, 250mm,1500mm,or be required
Length	1000mm,2000mm,2440mm,3000mm,3048mm,6000mm, or be required
Surface finish	2B,BA,HL,8K,No.1,No.4,No.8,Checkered ,etc
Chemical Composition	C≤0.030,Mn≤2.00,Si≤0.75, P≤0.040,S≤0.030,Ni11.00~15.00, Cr18.00~20.00,Mo≤3.00~4.00,N≤0.10
Mechanical Property	Rm≥515MPa,Rp0.2≥205MPa,A≥40%,HB≤217
Application	a) General service industries (petroleum, food, chemical, paper, fertilizer, fabric, aviation and nuclear) b) Fluid, gas and oil transport c) Construction and ornament
Package	Export standard package:bundled wooden box or be required; The inner size of container is below: (1)20footGP:5.8m(length)x2.13m(width)x2.18m(high)about 24-26 CBM (2)40footGP:11.8m(length)x2.13m(width)x2.72m(high)about 68 CBM We will packing as the factory, and reach the stander of export. Or as the customer request. In addition, We will make the products with good surface protection.
Delivery time	Normally according to the order quantity
Price term	FOB CIF CFR CNF etc
Market	Europe,South America, Africa ,Oceania ,such as : USA,Germany,India,Iran,Dubai,Iraq,Vietnam,Ireland, Singapore,and so on
Payment	T/T, L/C, and Western Union

About 317L material

317 l (00 cr19ni13mo3, UNS S31726) alloy is based on molybdenum austenitic stainless steel. It with conventional chrome - nickel austenitic stainless steel, such as, compared to 304 alloy has the stronger ability of resistance to chemical corrosion. In addition, compared with the conventional stainless steel, 317 l alloy has higher ductility, resistance to stress corrosion performance, compressive strength and resistance to high temperature performance. It is a low carbon level or L level, this level has during the welding and heat treatment process the sensitization effect of resistance.
Relative 316 l, 317 l steel has excellent water resistance and resistance to SCC, used for Chemical ships, Chemical products, such as Reactor should be high corrosion-resistant Chemical equipment.
SUS317L mechanical properties: YS (Mpa) 176 or higher, TS (Mpa) 480 or higher, EL (%) of 40 or higher, Hv 200 or less

Chemical Details

	C	Si	Mn	P	S	Ni	Cr	Mo
309	≤0.08	≤1.00	≤2.00	≤0.045	≥0.03	12.0-15.0	22.0-24.0	---
304	≤0.08	≤1.00	≤2.00	≤0.045	≤0.03	8.0-11.0	18.0-20.0	---
316	≤0.08	≤1.00	≤2.00	≤0.045	≤0.03	10.0-14.0	16.0-18.0	2.0-3.0
316L	≤0.03	≤1.00	≤2.00	≤0.045	≤0.03	10.0-14.0	16.0-18.0	2.0-3.0
317L	≤0.03	≤0.75	≤2.00	≤0.04	≤0.03	11.0-15.0	18.0-20.0	3.0-4.0
310S	≤0.08	≤0.75	≤2.00	≤0.045	≤0.03	19.0-22.0	24.0-26.0	---

Competitive Advantage:

high quality
fast deliver
storage company and keeps about 8000 ton products in stock.
the best price.
have a stainless steel products process center and we can do all kind of stainless steel process treatment.
near Shanghai port, the traffice is very convenient.

Alloy Grade 317L S31703 Stainless Steel Sheets 1250mm x 2438mm 2B Finished
