Monel 404 Shipbuilding 12mm Bright Round Bar

JIANGSU MITTEL STEEL INDUSTRIAL LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Monel 404 Shipbuilding 12mm Bright Round Bar

  • 1
  • 2
  • 3

Brand Name : Mittel

Model Number : Monel404

Certification : ISO,BV,SGS

Place of Origin : China

MOQ : 100KGS

Price : 23.5 USD/KG

Payment Terms : L/C, T/T

Supply Ability : 500000KGS

Delivery Time : 7 Working Days

Packaging Details : Wooden Pallet BOX

Type : Round

Application : decoration,Industry,Mechineal,shipbuilding

Standard : DIN,ASTM

Grade : Monel404

Shape : Round

Dimensions : 5.5mm-500mm

Surface : bright,Polished

Technique : Cold drawn&hot rolled

Packing : Standard Seaworthy Package

Contact Now

Monel 404 alloy is used primarily in specialized electrical and electronic applications.The composition of Monel 404 is carefully adjusted to provide a very low Curie temperature, low permeability, and good brazing characteristics.

Monel 404 can be welded using common welding techniques and forged but cannot be hot worked. Cold working may be done using standard tooling and soft die materials for better finish. It is covered by standards UNS N04404 and ASTM F96. This alloy is used in the following applications: capsules for transistors and ceramic to metal sealings.

Chemical composition:

Grade Chemical Component %
C Si Mn S Ni+Co Fe Cu Al
Monel 404 Max 0.15 Max 0.10 Max 0.10 Max 0.024 52.0-57.0 Max 0.50 Balance Max 0.05


Application:
1. capsules for transistors
2. ceramic-to-metal sealing

Available products for Monel 404:
Welded pipe/tube
Seamless pipe/tube
Pipe fittings
Flanges
Bar/Profiles
Sheet/ Plate/Coil/Strip
Wire/Wire rope
Forgings
Welding Rod
Fastener

Monel 404 Shipbuilding 12mm Bright Round BarMonel 404 Shipbuilding 12mm Bright Round BarMonel 404 Shipbuilding 12mm Bright Round Bar
